JAC-K788TM Surface Conditioning Flap Discs

JAC-K788TM Surface Conditioning Flap Discs

Availability

Product Code	JAC-K788TM	JAC-K788TM	JAC-K788TM
Abrasive Grains	Refined Alumina Non-woven	Refined Alumina Non-woven	Refined Alumina Non-woven
Flap Disc Density	Standard	Standard	Standard
Flap Fitted Versions	Single	Single	Single
Backing Plate Material	Reinforced Fiberglass	Reinforced Nylon	Turbo-Cooling Trim Plastic
Flap Disc Shape Available	T29-Conical/T28-Convex/T27-Flat	T29-Conical/T28-Convex/T27-Flat	T29-Conical/T27-Flat

BRITSH SIZE	METRIC SIZE	GRIT	MAX	STD	PART #			PART #			PART #
( D x H )	( D x H )	GRIT	RPM	PACK	T27	T28	T29	T27	T28	T29	T27	T28	T29
4" x 5/8"	100 mm x 16 mm	CRS	15,300	10	76005	77105	76006	76550	77350	76551
		MED			76018	77118	76019	76563	77363	76564
		FIN			76021	77121	76022	76576	77376	76577
		VFN			76034	77134	76035	76589	77389	76580
		SFN			76047	77147	76048	76592	77392	76593
4-1/2" x 7/8"	115 mm x 22.23 mm	CRS	13,300	10	76050	77150	76051	76605	77405	76606	76850		76851
		MED			76063	77163	76064	76618	77418	76619	76863		76864
		FIN			76076	77176	76077	76621	77421	76622	76876		76877
		VFN			76089	77189	76080	76634	77434	76635	76889		76880
		SFN			76092	77292	76093	76647	77447	76648	76892		76893
5" x 7/8"	125 mm x 22.23 mm	CRS	12,200	10	76105	77305	76106	76650	77450	76651	76905		76906
		MED			76118	77318	76119	76663	77463	76664	76918		76919
		FIN			76121	77321	76122	76676	77476	76677	76921		76922
		VFN			76134	77334	76135	76689	77498	76680	76934		76935
		SFN			76147	77347	76148	76692	77492	76693	76947		76948
6" x 7/8"	150 mm x 22.23 mm	CRS	10,200	10	76150		76151
		MED			76163		76164
		FIN			76176		76177
		VFN			76189		76180
		SFN			76192		76193
7" x 7/8"	180 mm x 22.23 mm	CRS	8,600	10	76205		76206	76705		76706	76950		76951
		MED			76218		76219	76718		76719	76963		76964
		FIN			76221		76222	76721		76722	76976		76977
		VFN			76234		76235	76734		76735	76989		76980
		SFN			76247		76248	76747		76748	76992		76993
4-1/2" x 5/8"-11	115 mm x M14-2	CRS	13,300	5	76250		76251				77005		77006
		MED			76263		76264				77018		77019
		FIN			76276		76277				77021		77022
		VFN			76289		76280				77034		77035
		SFN			76292		76293				77047		77048
5" x 5/8"-11	125 mm x M14-2	CRS	12,200	5	76305		76306				77050		77051
		MED			76318		76319				77063		77064
		FIN			76421		76422				77076		77077
		VFN			76434		76435				77089		77080
		SFN			76447		76448				77092		77093
6" x 5/8"-11	150 mm x 5/8"-11	CRS	10,200	5	76450		76451
		MED			76463		76464
		FIN			76476		76477
		VFN			76489		76480
		SFN			76492		76493
7" x 5/8"-11	180 mm x 5/8"-11	CRS	8,600	5	76505		76506
		MED			76518		76519
		FIN			76521		76522
		VFN			76534		76535
		SFN			76547		76548
