Back-up Pads for Surface Conditioning Discs

  • Back-up Pads for Surface Conditioning Discs
  • Back-up Pads for Surface Conditioning Discs
  • Back-up Pads for Surface Conditioning Discs
  • Back-up Pads for Surface Conditioning Discs
Availability
Product Code JAC-A216BP JAC- A226BP JAC-A236BP
Back-UP Pads Shape Flat Flat with Turbo Quick Change with Turbo
SIZE ( D x H ) SIZE ( D x H ) MAX STD PART # PART # PART #
RPM PACK
4" x 3/8"-24 100 x 3/8"-24 15,300 5 21106 21248 21380
4" x M10-1.5 100 x M10-1.5 15,300 5 21119 21251 21393
4" x M14-2 100 x M14-2 15,300 5 21122 21264 21406
4-1/2" x 5/8"-11 115 mm x 5/8"-11 13,300 5 21135 21277 21419
4-1/2" x M10-1.5 115 mm x M10-1.5 13,300 5 21148 21280 21522
4-1/2" x M14-2 115 mm x M14-2 13,300 5 21151 21293 21535
5" x 5/8"-11 125 mm x 5/8"-11 12,200 5 21164 21306 21548
5" x M14-2 125 mm x M14-2 12,200 5 21177 21319 21551
6" x 5/8"-11 150 mm x 5/8"-11 10,200 5 21180 21322 21564
6" x M14-2 150 mm x M14-2 10,200 5 21193 21335 21577
6" x M16-2 150 mm x M16-2 10,200 5 21206 21348 21580
7" x 5/8"-11 180 mm x 5/8"-11 8,600 5 21219 21351 21593
7" x M14-2 180 mm x M14-2 8,600 5 21222 21364 21606
7" x M16-2 180 mm x M16-2 8,600 5 21235 21377 21619
Back-up Pads for Surface Conditioning Discs
